501069 | 2in Ford Strut Leveling Kit (09-13 F-150)

2009-2013 Ford F150 Pickup 4WD

SKU: 501069

Pricing: $461.95

Description
Vehicle Applications
Tires & Wheels
Components
Tires & Wheels
Details
Shipping

Description

Level your vehicle from front to rear while preserving the smooth, factory ride quality with Rough Country's N3 Strut Leveling Kit! This easy-to-install kit boosts the front end, removing the unsightly factory rake and giving your truck increased ground clearance and aggressive good looks.

Rough Country’s N3 Struts feature a massive bore and chrome plated piston rod with leak-proof piston seal for exceptional durability during off-road use. Each strut is tuned to OEM specs and includes a variable dampening system for outstanding handling and control on all road conditions. These struts offer improved tire contact with the road for increased stability and performance. Each lifted strut is a full replacement of your OEM equipment, engineered for a pain-free installation. Simply remove the factory strut and replace for an instant upgrade! No complicated strut disassembly required!

FEATURES
Easy bolt-on installation
Includes pre-loaded coil
No strut disassembly required
Maintains smooth, factory-like ride
Increased ground clearance
Application specific velocity sensitive valving
Structurally engineered for lifted applications
Levels the front of the vehicle by 2-inches, eliminating the need for strut spacers
Nitrogen gas charged to improve ride, handling, and reduce shock oil aeration
Offers improved tire contact with the road for increased stability and performance
Infinitely Variable Damping
Leak-proof piston seal
Special formulated low friction shock oil
Massive 1 3/8in Bore
Hardened chromed piston rod provides superior corrosion resistance and enhances sealing properties
3-year Limited Warranty
Black powder coat finish

NOTES - IMPORTANT
Does NOT fit Raptor Models

SPECS
SKU 501069
Mounting Location Front
Extended Length (in) 22.87
Collapsed Length (in) 18.3
Adjustable No
Est. Install Time 1-2 hours

Vehicle Applications

2009 - 2013 Ford F-150 Pickup

NOTES - IMPORTANT
Does NOT fit Raptor Models

Tires & Wheels

295/60R20 Factory 20 6x135 - 0.25 Spacer
285/75R17 Factory 17 6x135 - -
285/70R18 Factory 18 6x135 - -
33x12.50R17 17x8.5 6x135 +0 -
285/70R17 17x8.5 6x135 +0 -
33x12.50R17 17x8.5 6x135 +1 -
33x12.50R17 17x9 6x135 -12 -
285/70R17 17x9 6x135 -12 -
33x12.50R17 17x9 6x135 +0 -
285/70R17 17x9 6x135 +0 -
33x12.50R17 17x9 6x135 +1 -
285/70R17 17x9 6x135 +1 -
33x12.50R17 17x9 6x135 +18 -
285/70R17 17x9 6x135 +18 -
33x12.50R18 18x8.5 6x135 +0 -
305/60R18 18x8.5 6x135 +0 -
33x12.50R18 18x8.5 6x135 +1 -
305/60R18 18x8.5 6x135 +1 -
33x12.50R18 18x9 6x135 -12 Trimming Required
285/65R18 18x9 6x135 -12 -
33x12.50R18 18x9 6x135 +0 -
305/60R18 18x9 6x135 +0 -
33x12.50R18 18x9 6x135 +1 -
305/60R18 18x9 6x135 +1 -
285/65R18 18x9 6x135 +1 -
33x12.50R18 18x9 6x135 +18 -
305/60R18 18x9 6x135 +18 -
33x12.50R18 18x9 6x135 +20 -
305/60R18 18x9 6x135 +20 -
33x12.50R20 20x9 6x135 -12 -
305/55R20 20x9 6x135 -12 -
295/60R20 20x9 6x135 -12 Minor Trimming
285/55R20 20x9 6x135 -12 -
33x12.50R20 20x9 6x135 +0 -
305/55R20 20x9 6x135 +0 -
295/60R20 20x9 6x135 +0 Minor Trimming
285/55R20 20x9 6x135 +0 -
33x12.50R20 20x9 6x135 +1 -
305/55R20 20x9 6x135 +1 -
295/60R20 20x9 6x135 +1 Minor Trimming
285/55R20 20x9 6x135 +1 -
33x12.50R20 20x9 6x135 +18 -
305/55R20 20x9 6x135 +18 -
33x12.50R20 20x9 6x135 +20 -
305/55R20 20x9 6x135 +20 -
295/60R20 20x9 6x135 +20 Minor Trimming
285/55R20 20x9 6x135 +20 -
33x12.50R20 20x10 6x135 -25 Trimming Required
305/55R20 20x10 6x135 -25 -
295/60R20 20x10 6x135 -25 Trimming Required
285/55R20 20x10 6x135 -25 -
33x12.50R20 20x10 6x135 -24 Trimming Required
305/55R20 20x10 6x135 -24 -
295/60R20 20x10 6x135 -24 Trimming Required
285/55R20 20x10 6x135 -24 -
33x12.50R20 20x10 6x135 -19 Trimming Required
305/55R20 20x10 6x135 -19 -
295/60R20 20x10 6x135 -19 Trimming Required
285/55R20 20x10 6x135 -19 -
33x12.50R20 20x10 6x135 -18 Trimming Required
305/55R20 20x10 6x135 -18 -
295/60R20 20x10 6x135 -18 Trimming Required
285/55R20 20x10 6x135 -18 -
33x12.50R20 20x12 6x135 -44 Trimming Required
305/55R20 20x12 6x135 -44 -
33x12.50R22 22x10 6x135 -25 Trimming Required
33x12.50R22 22x10 6x135 -24 Trimming Required
33x12.50R22 22x10 6x135 -19 Trimming Required
33x12.50R22 22x10 6x135 -18 Trimming Required
33x12.50R22 22x12 6x135 -44 Trimming Required
