27970 | 6 Inch Lift Kit | NTD | V2 | Chevy Avalanche 1500 (02-06)/Suburban 1500 (00-06)

2002-2006 Chevrolet Avalanche 1500 2WD/4WD | 2000-2006 Chevrolet, GMC Suburban 1500, Yukon XL 1500 2WD/4WD

27970
Pricing: $1,690.95
Qty:
Free Ground Shipping | Exclusions Apply*

Description

We've raised the bar for our popular 6" '00 - '06 Tahoe, Yukon, Suburban Lift! We've phased out our torsion drop kit to offer the more popular and better performing Non Torsion Drop option. This NTD kit is easier to install, handles better than ever, and looks killer from any angle since you won't have that unsightly torsion bar peeking out from the underside of the vehicle. Gain greater clearance, better handling, and the cleanest looking 6" lift available! A set of lifted front knuckles and rear coil springs allow your SUV to run up to 35" tires, while a full set of high-clearance crossmembers, differential drop brackets and torsion bar drop brackets keep everything tucked, hidden, and at optimum angles. But the best gets even better: Now included in this kit are a set of front N3 Shocks - custom valved to the specifics of your model vehicle, and designed for balanced performance both on and off-road. Front CV spacers, sway-bar links, and a protective skid plate are also included to give you everything you need to get rolling in one of our best kits, at our best price.

FEATURES
Torsion bars stay in factory location
Redesigned for easier installation
Maintains factory ride quality
Applicable with Auto Trac equipped models
Unmatched ground clearance
Axles maintain factory position and angle
No drivetrain or exhaust modifications required
Designed to reuse factory compression travel stops
Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.

NOTES - IMPORTANT
Frame bracket modification required
New fabricated lift block replaces your factory equipped block.
If equipped with factory 17" wheels and purchasing new wheels - the new wheels must be 17" or larger.
Does not fit models fit autoride/auto leveling feature
Torsion bar unloading tool required for installation. Available below (#1067)

SPECS
SKU 27970
Est. Install Time 8 - 10 hours

Vehicle Applications

2002 - 2006 Chevrolet Avalanche 1500
2000 - 2006 Chevrolet Suburban 1500
2000 - 2006 GMC Yukon

NOTES - IMPORTANT
Frame bracket modification required New fabricated lift block replaces your factory equipped block.
If equipped with factory 17" wheels and purchasing new wheels - the new wheels must be 17" or larger.
Does not fit models fit autoride/auto leveling feature Torsion bar unloading tool required for installation.
Available below (#1067)

Components

FRONT
Lifted knuckles
Front crossmember
Rear crossmember
Non-torsion bar drop brackets
Differential drop brackets
CV spacers
Lower skid plate
Sway-bar links
Hardware

REAR
Lifted coil springs

SHOCKS
(2) Front V2 Monotube series

Tires & Wheels

35x12.50R17 17x9 6x5.5 +18 Minor Trimming
35x12.50R17 17x9 6x5.5 +20 Minor Trimming
305/70R17 17x9 6x5.5 -12 -
305/70R17 17x9 6x5.5 +0 -
305/70R17 17x9 6x5.5 +1 -
295/70R18 18x9 6x5.5 +0 Minor Trimming
295/70R18 18x9 6x5.5 +1 Minor Trimming
35x12.50R18 18x9 6x5.5 +18 Minor Trimming
35x12.50R18 18x9 6x5.5 +20 Minor Trimming
295/60R20 20x9 6x5.5 +0 Minor Trimming
295/60R20 20x9 6x5.5 +1 Minor Trimming

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 125.0 lbs.
  • W24.0000” x H12.0000” x L48.0000”
  • Free Ground Shipping | Exclusions Apply*
