40145 | VIAIR 400P EF Automatic Portable Compressor / Tire Inflator With Inline 160 PSI Gauge Inflation Gun | 150 PSI, 12 Volt Power Battery Clamps With 2-Pin SAE Connector

The 400P EF Automatic is an updated version of our popular 400P Automatic Portable. It features VIAIR's new EF (Enhanced Flow) Technology that delivers up to 10% faster fill and 20% more performance, getting you back on the road faster than ever.

EF compressors also feature an SAE power cord that allows you to use different power attachments for maximum versatility, an updated head for better heat dissipation and the same legendary VIAIR durability.

SPECIFICATIONS

• PN: 40145
• 12-Volt
• Permanent Magnetic Motor
• Duty Cycle: 100% @ 40 PSI - 33% @100 PSI
• Max. Working Pressure: 150 PSI
• Max. Amp Draw: 30-Amps
• Ingress Protection Rating: IP54
• Max. Ambient Temp: 158°F
• Max. Ambient Temp: -40°F
• Dimensions: 10.9" x 5.8" x 7.4"
• Net Weight: 10.35 lbs.
• Power Cord Length: 6 ft.
• Air Hose Length: 30ft.

FEATURES:

• EF (Enhanced Flow) Technology
• 2-Pin SAE Power connection with 40-Amp inline fuse holder
• Gas Station-Style Tire Inflation Gun with 160 PSI Gauge
• Primary & Extension Air Hoses
• Quick Connect Air Hose with Heat Shield
• 3 pc. Inflation Tips Kit and Presta valve Adapter
• Patented I-Beam Sand Tray
• Stealth Black Look
• Rugged Carry Bag
• High Flow output for Oversize Tires

FILL RATES

• 35 x 12.5 R15 FILL RATE
  • 0 to 40 PSI 6 min. 25 sec. (+/- 15 sec.)
  • 10 to 40 PSI 4 min. 56 sec. (+/- 15 sec.)
• 37 x 12.5 R15 FILL RATE
  • 0 to 40 PSI 7 min. 15 sec. (+/- 15 sec.)
  • 10 to 40 PSI 5 min. 30 sec. (+/- 15 sec.)

Performance
